Trek Fuel EX 9.8 XT (Gen 7) Full Suspension Bike 2026

Fuel EX 9.8 XT is a versatile and adaptable carbon MTB built to tackle any trail, anytime. Its OCLV Mountain Carbon frame pairs with a Fox Factory suspension package (145mm rear, 150mm front) to deliver traction and stability in the rough. A mechanical Shimano XT 12-speed drivetrain gives you clean, reliable shifting and 4-piston XT M8200 brakes provide excellent modulation and stop-on-a-dime power.

TECHNICAL SPECIFICATIONS

*Please note - spec applies to all sizes unless listed separately

Frameset
Specifications
*Frame    Size: S, XL, L, M, XXL
OCLV Mountain Carbon, internal storage, ZS headset, adjustable leverage rate, guided internal routing, interchangeable alloy rocker link, interchangeable lower shock mount, downtube guard, shuttle guard, BSA 73, ISCG 05, ABP, UDH, Boost148, adaptable travel 145mm-160mm
*Fork    Size: S, XL, L, M, XXL
Fox Factory 36, Float EVOL air spring, GRIP X2 damper, 44mm offset, Boost 110, 15mm Kabolt X axle, 150mm travel
*Shock    Size: S, XL, L, M, XXL
Fox Factory Float X, 205mm x 60mm

Wheels
Specifications
*Front Wheel    Size: S, XL, L, M, XXL
Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29"
*Rear Wheel    Size: S
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5"
Size: XL, L, M, XXL
Bontrager Line Comp 30, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 29"
*Rear Skewer    Size: S, XL, L, M, XXL
Bontrager Switch thru axle, removable lever
*Tire    Size: S, XL, L, M, XXL
Maxxis Minion DHF, tubeless ready, 3C, EXO+ casing, MAXXGRIP, folding bead, 29x2.5''
Size: S
Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 27.5x2.5''
Size: XL, L, M, XXL
Maxxis Minion DHR II, tubeless ready, 3C, EXO+ casing, MAXXTERRA, folding bead, 29x2.5''
*Tire Part    Size: S, XL, L, M, XXL
Bontrager TLR sealant, 180 ml/6 oz
Max tire size    Frame: 29x2.50", Fork: See manufacturer

Drivetrain
Specifications
*Shifter    Size: S, XL, L, M, XXL
Shimano XT M8100, 12 speed
*Rear Derailleur    Size: S, XL, L, M, XXL
Shimano XT M8100, long cage
*Crank    Size: S, XL, L, M, XXL
Shimano XT M8120, 30T, 55mm chainline, 170mm length
*Bottom Bracket    Size: S, XL, L, M, XXL
Shimano BB-MT501 BSA
*Cassette    Size: S, XL, L, M, XXL
Shimano XT M8200, 10-51, 12 speed
*Chain    Size: S, XL, L, M, XXL
Shimano Ultegra/XT M8100, 12 speed
Max chainring size    1x: 34T round, 32T oval, min 30T, 32T oval

Components
Specifications
*Saddle    Size: S, XL, L, M, XXL
Verse Short Pro, carbon rails, 145mm width
*Seatpost    Size: S
Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length
Size: M
Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length
Size: XL, L, XXL
Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 5150mm length
*Handlebar    Size: S, XL, L, M, XXL
Race Face ERA, carbon, 35mm, 27.5mm rise, 800mm width
*Grips    Size: S, XL, L, M, XXL
Trek Line Elite, lock-on
*Stem    Size: S, XL, L, M, XXL
Bontrager Elite, 35mm, 0 degree, 45mm length
*Brake    Size: S, XL, L, M, XXL
Shimano XT M8200 4-piston hydraulic disc
*Brake Rotor    Size: S, XL, L, M, XXL
Shimano RT86, 6-bolt, 203mm
Size: S, XL, L, M, XXL
Shimano RT86, 6-bolt, 180mm
Rotor size    Max brake rotor sizes - Frame: 203mm, min 180mm, Fork: see fork manufacturer

Weight
Specifications
Weight    M - 15.28 kg / 33.69 lbs (with TLR sealant, no tubes)
Weight limit    This bike has a maximum total weight limit (combined weight of bicycle, rider, and cargo) of 300 pounds (136 kg).

We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colors, materials, and pricing. Due to supply chain issues, compatible parts may be substituted at any time without notice.

Bike and frame weights are based off pre-production painted frames at time of publication. Weights may vary in final production.
